Efficient and Flexible
● Cutting, stripping, blanking in one pass for up to 9,000 sheets/hour
● Synchronized feeder and register provide extremely accurate non-stop feeding
● High flexibility for short-run jobs, non-stop production for long –run jobs
Hassle-free blanks ready for the next step
● Amazing blank quality, ready for next step
● Automatic sheet inserter, delivering perfect blank piles
Cost-effective design
● Minimizing operator intervention and maximizing uptime by high automation
● Easy accessibility, fast setting and changeovers for optimal productivity
Intelligent Feeder
● Motorized side adjustment of Pallet table (+/-35mm), ensuring precise feeding
● Non-stop system for Feeder Section
● Movable gangway puts adjustment elements within easy reach
● Continuous and stable sheet feeding with perfect material positioning enable to run various weight of stocks precisely
● Auxiliary air blower can be adapted from thin material to cardboard
Feed Table Register
● Front lays register device with 4 sensors brings each sheet into perfect cut-to-print register
● Optical lateral sheet register: Lateral sensors identify
● Sheet edge for automatic centering
● Ultrasonic double sheet detector without making contact with jobs leading to scratch free
Die Cutting Section
● Double cam drive system conveying sheets in the smoothest way possible
● FCD 600 high rigidity platen with 4 ways +/- 0.9mm micro adjustment
● Motorized adjustment of cutting pressure up to 260 tons
● 2 quick lock die-cutting chases for quick and easy setting which are locked and pushed by pneumatic system
State-Of-Art Gripper Bar
● 8 pieces of state-of-art gripper bar from SBL latest technology, which allows minimum number and size of nicks at reasonable maximum production speed due to the unique design of large-motion
● Angle eccentric worm gear drive system
● Carbon fiber gripper bar, lightweight in design & high rigidity for enduring performance
● Access to sample sheet with gripper opener using pneumatic at Stripping Section
In-Line Stripping Section
● Upper frame with quick lock mechanism
● Center line and register system for stripping
Blanking & Blank Pile Delivery
● Upper frame with quick lock mechanism
● Center line and register system for blanking
● Automatic sheet inserter
● Automatic non-stop rack for continuous production -Air sheet braking unit /sheet tail suction device increases the stability of the sheet movement and allows smooth transfer
● Automatic non-stop rack for continuous production
● In-ground conveyor for efficient operation
